SPECIFICATION
| Brake Shoe Width: | 7″ | GAWR: | 23k lbs |
| Brake Size: | 16.5″ x 7″ | Application Notes: | quick change Q+ extended service; ID TIPS – 4707Q has: + in rivet table (some designs) vs no + on 4515Q and has no hump in web vs slight hump on 4515Q |
| FMSI Number: | 4707Q | Service Type: | Standard / Heavy Haul |
| Kit Notes: | includes pair of brake shoes and hardware kit to cover replacement on one wheel end | New or Relined: | New |
| Brake Diameter: | 16.50 | Shoe Series: | Q+ |
| Application: | Meritor |
Product Details
The Torlast Heavy Haul Brake Shoe Kit 23,000 GAWR by not only meets, but also exceeds, all FMVSS121 brake standard requirements for 23K pound axles (165 AL Factor). With deluxe braking power, this truck and trailer part can be used on a variety of heavy duty vehicles, such as single axle tractors and trailers, car haulers, container chassis, double trailers, flat bed trailers, and tandem axle tractor and trailers. It is the ideal match for both on- and off-highway driving. The brake shoe kit also boasts extended wear life and minimal drum deterioration, which significantly reduces downtime and maintenance.
FEATURES
- 16.5″ x 7″
- Shoe type: 4707Q
- Exceptional crack prevention due to first-rate flex strength and elasticity
- Premium friction stability and performance from high-temperature resins
- Brake shoe steel tested to over 1,000 salt spray hours
- Asbestos- and copper-free brake lining with medium/high-friction
- Glass-aramid based fiber provides high tensile strength
- Exceeds the FMVSS 121 brake standard at 23,000 pounds (165 AL Factor)
- Ideal for container chassis, flatbed trailer, car haulers, low profile moving vans, school buses, and double trailer applications
Cross Reference
GLN4707Q23KIT
NKHS4707QP
| ARVIN |
KSF5574707QP
|
| MERITOR |
KSMA23014707QPR
MNK4707QH23P
|
| OTR |
K4707QHH23
KITOTR4707QRED
|
Warranty
| Warranty Time Period | 1 Year |
| Warranty Code | B |
