SPECIFICATION
| Brake Size: | 16.5″ x 7″ | Kit Notes: | includes pair of brake shoes and hardware kit to cover replacement on one wheel end |
| Brake Diameter: | 16.50 | FMSI Number: | 4709E2 |
| GAWR: | 23k lbs | New or Relined: | New |
| Brake Shoe Width: | 7″ | Shoe Series: | ES2 |
| Application: | Eaton Spicer | Service Type: | Standard / Heavy Haul |
| Application Notes: | single anchor pin – ES2 series, 2nd design; ID TIPS – 4709E2 has fixed spring clip and has no holes at end of table vs holes on 4311E and 4709E | ||
Product Details
The Torlast Heavy Haul Brake Shoe Kit not only meets, but also exceeds all FMVSS121 brake standard requirements for 23K pound axles (165 AL Factor). With optimal braking power, this semi truck and trailer part can be used on a variety of heavy duty vehicles, such as single axle tractors and trailers, car haulers, container chassis, double trailers, flat bed trailers, and tandem axle tractor and trailers. It is the ideal match for both on- and off-highway driving. The brake shoe kit replacement also boasts extended wear life and minimal drum deterioration, which significantly reduces downtime and maintenance.
FEATURES
- 16.5″ x 7″ brake shoe
- Shoe type: 4709E2
- Exceptional crack prevention due to first-rate flex strength and elasticity
- Premium friction stability and performance from high-temperature resins
- Brake shoe steel tested to over 1,000 salt spray hours
- Asbestos- and copper-free brake lining with medium/high-friction
- Glass-aramid based fiber provides high tensile strength
- Exceeds the FMVSS 121 brake standard at 23,000 pounds (165 AL Factor)
- Great for container chassis, flatbed trailer, car haulers, low profile moving vans, school buses, and double trailer applications
Cross Reference
GLN4709E223KIT
KSF5574709ES2
MNK4709E2H23
NKHS4709E2
XKMG24709E2
| MERITOR |
MNK4709E2H23P
|
| OTR |
K4709E2HH23
KITOTR4709E2RED
|
Warranty
| Warranty Time Period | 1 Year |
| Warranty Code | B |
