SPECIFICATION
| Shoe Series: | Q+ | Application Notes: | Meritor Q Plus |
| Service Type: | Premium | Application: | Meritor |
| Brake Shoe Width: | 8.63 | New or Relined: | New |
| Brake Diameter: | 16.50 | FMSI Number: | 4711Q |
| Brake Size: | 16.50 in x 8.63 in |
Product Details
The Torlast Heavy Haul Brake Shoe Kit not only meets, but also exceeds all FMVSS121 brake standard requirements for 23K pound axles (165 AL Factor). With optimal braking power, this semi truck and trailer part can be used on a variety of heavy duty vehicles, such as single axle tractors and trailers, car haulers, container chassis, double trailers, flat bed trailers, and tandem axle tractor and trailers. It is the ideal match for both on- and off-highway driving. The brake shoe kit replacement also boasts extended wear life and minimal drum deterioration, which significantly reduces downtime and maintenance.
FEATURES
- 16.5″ x 7″
- Shoe type: 4711Q
- First-rate flex strength and elasticity providing exceptional crack prevention
- High-temperature resins lends to exceptional crack prevention
- 1,000 salt spray hours of brake shoe steel testing
- Asbestos- and copper-free brake lining with medium/high-friction
- Provides high tensile strength with glass-aramid based fiber
- Exceeds the FMVSS 121 brake standard at 23,000 pounds (165 AL Factor)
- Great for container chassis, flatbed trailer, car haulers, low profile moving vans, school buses, and double trailer applications
Cross Reference
MNK4711QH23
NKHS4711QP
XKMG24711QP
| FLEETPRIDE |
BK4711QPAR3
|
| MERITOR |
KSF5234711QP
MNK4711QH23P
|
| OTR |
K4711QHH23
KITOTR4711QRED
|
Warranty
| Warranty Time Period | 1 Year |
| Warranty Code | B |
